| Specification | |
| Size | METRIC SERIES: M12, M14,M16, M18, M20, M22,M24, M27, M30, M33,M36, M42, M45, M48,M52, M56, M64, M72 INCH SERIES: 7/16”, 1/2”, 9/16” 5/8”, 3/4”, 7/8”, 1”, 1.1/8”,1.1/4”,1.3/8”, 1.1/2”,1.5/8”,1.3/4”, 1.7/8”,2”,2.1/4”, 2.1/2” |
| Grade | "GR.4.6, 5.6, 8.8, 10.9, 12.9Gr.8.8 , 10.9GR.B7,B7M,B8,B8M,B16GR.660 (ENCONEL STEEL)BS 1768 GR. S,VBS 1083 GR. A,B,TGR. B8,B8M,B7,B7M,B16GR. L7/L7MGR.660 (ENCONEL STEEL)" |
| Dimension | "IS 1364 Part 2IS 1363 Part 2DIN 931ASME B18.2.3.3MASME B18.2.3.3MBS 1768BS 1083ASME B18.2.1ASME B18.2.3.3M" |
| Chemical & Mechanical | "IS 1367 PART 3ISO 898-PART 1ASTM A193ASTM A453BS 1768BS1083ASTM A193ASTM A320ASTM A453" |
| Finish | "HOT DIP GALVANISED : IS 1367 PT 13 IS: 4759 BS EN: 1461, ASTM A153 ASTM A123 BLACK PHOSPHATE: IS 1367 PT 12ELECTRO GALVANISED : IS: 1367 PT 11 , IS: 1573" |
| Specification | |
| Size | METRIC SERIES: M16, M18, M20, M22, M24, M27, M30, M33 M36 INCH SERIES: 1/2”,5/8”, 3/4”, 7/8”, 1”, 1.1/8”, 1.1/4”, 1.3/8”, 1.1/2” |
| Grade | GR.8S ,10S GR. B7,B7M,B16,B8,B8M ASME B18.2.3.3M ASTM A193 GR.660(ENCONEL STEEL) GR. L7,L7M ASTM F3125-TYPE 1 ASTM A490 TYPE 1 ASTM A307 GR.A & B |
| Dimension | IS 3757 ASME B18.2.3.3M ASME B18.2.6M ASME B18.2.6 ASME B18.2.1 |
| Chemical & Mechanical | IS 1367 PART 3 ASTM A193 ASTM A453 ASTM A320 ASTM F3125 ASTM A490 ASTM A307 |
| Finish | HOT DIP GALVANISED : IS 1367 PT 13 IS: 4759 BS EN: 1461, ASTM A153 ASTM A123 BLACK PHOSPHATE: IS 1367 PT 12 ELECTRO GALVANISED : IS: 1367 PT 11 , IS: 1573 |
