| Specification | |
| Size | METRIC SERIES: M10 M12, M14, M16, M18, M20, M22, M24, M27, M30, M33 M36, M39, M42, M45, M48, M52, M56, M64, M72 |
| Grade | IS 2062 GR. A GR.45C8 IS 2062 GR. A IS 2062 GR. A IS 2062 GR. A GR.45C8 GR.45C8 |
| Dimension | IS 2016 IS 2016 DIN 125 IS 5369 DIN 9021 IS 6610 BS EN 14399 PART 5 |
| Chemical & Mechanical | IS 2062 GR. A IS 1570 PART 2 IS 2062 GR. A IS 2062 GR. A IS 2062 GR. A IS 1570 PART 2 IS 1570 PART 2 |
| Finish | HOT DIP GALVANISED : IS 1367 PT 13 IS: 4759 BS EN: 1461, ASTM A153 ASTM A123 BLACK PHOSPHATE: IS 1367 PT 12 ELECTRO GALVANISED : IS: 1367 PT 11 , IS: 1573 |
| Specification | |
| Size | METRIC SERIES: M10 M12, M14, M16, M18, M20, M22, M24, M27, M30, M33, M36 |
| Grade | GR.70C6 |
| Dimension | IS 3063 |
| Chemical & Mechanical | IS 3063 |
| Finish | HOT DIP GALVANISED : IS 1367 PT 13 IS: 4759 BS EN: 1461, ASTM A153 ASTM A123 BLACK PHOSPHATE: IS 1367 PT 12 ELECTRO GALVANISED : IS: 1367 PT 11 , IS: 1573 |
