| Specification | |
| Size | METRIC SERIES: M12, M14, M16, M18, M20, M22, M24, M27, M30, M33 M36, M39, M42, M45, M48, M52, M56, M64, M72 INCH SERIES: ½”,9/16”,5/8”,3/4”, 7/8”,1”,1.1/8”,1.1/4”, 1.3/8”,1.1/2”,1.5/8”, 1.3/4”,1.7/8”,2”, 2.1/4”,2.3/8” 2.1/2”,2.5/8” 2.3/4”, 2.7/8”, 3”, 3.1/4”, 3.3/8” 3.1/2” , 3.5/8”, 3.3/4”, 3.7/8”, 4” |
| Grade | GR.B7 ,B7M,B16 GR.A307 GR. A & B GR.L7,L7M, GR.660 (ENCONEL STEEL) B8,B8 CL-2 |
| Dimension | ASME B18.2 |
| Chemical & Mechanical | ASTM A193 ASTM A307 ASTM A320 ASTM A453 |
| Finish | HOT DIP GALVANISED : IS 1367 PT 13 IS: 4759 BS EN: 1461, ASTM A153 ASTM A123 BLACK PHOSPHATE: IS 1367 PT 12 ELECTRO GALVANISED : IS: 1367 PT 11, IS: 1573 |
